The 20-inch melt-blown PP filter cartridge is engineered with a multi-layer gradient structure to efficiently remove suspended particles, rust, sediment, and impurities…

OD 2.5 inch
Height 20 inch
End caps
Filter layer Polypropylene
Filtration rate 1 µm, 5 µm, 10 µm, 20 µm, 50 µm μm
Working temperature 5°C to 60°C (41°F to 140°F)
Skeleton

Send Email WhatsApp
Share:

Product Details

Learn more about the specifications, features and benefits of our high-performance filter element.

Description

The 20-inch melt-blown PP filter cartridge is engineered with a multi-layer gradient structure to efficiently remove suspended particles, rust, sediment, and impurities from water. Manufactured from 100% food-grade polypropylene without any chemical binders, it is the ideal, cost-effective pre-filtration solution for reverse osmosis systems, whole-house water filtration, and food & beverage processing.


Application
Designed for versatile pre-filtration across residential, commercial, and industrial settings:

Residential Water Treatment

l Whole-house sediment filtration to protect household appliances (water heaters, washing machines).

l Pre-filter stage for under-sink RO (Reverse Osmosis) systems and UV sterilizers.

Commercial & Public Facilities

l Pre-filtration for commercial drinking water fountains, office water dispensers, and restaurant beverage equipment.

l Swimming pool and spa water pre-treatment.

Food & Beverage Industry

l Pre-treatment for process water, ingredient water, and wash water in food processing plants, breweries, and bottling lines.

l Protection of downstream micro-filtration and ultra-filtration (UF) membranes.

Light Industrial & Manufacturing

l Pre-filtration for cooling tower makeup water and small-scale industrial circulating water systems.

l Electronics manufacturing pre-RO water treatment, electroplating solution pre-filtration, and general utility water purification.

l Agricultural irrigation systems to prevent emitter clogging.



Frequently Asked Questions (FAQ)

Q1: What is the difference between melt-blown filters and string-wound filters?

A: Melt-blown filters use a thermal-bonded gradient polypropylene web structure for high-efficiency particle retention. String-wound filters use twisted yarn patterns, which are typically better suited for high-viscosity liquids.

Q2: What micron rating should I choose for RO pre-filtration?

A: 5 µm or 10 µm PP melt-blown cartridges are the most popular choices for RO system pre-filtration to effectively protect the high-pressure pump and membrane.

Q3: Can this filter cartridge be cleaned and reused?

A: No. This is a disposable depth filter. Attempting to wash or reuse it may damage the gradient structure and compromise filtration performance.

Q4: Is this safe for drinking water?

A: Yes. It is made of 100% food-grade polypropylene with no chemical binders, making it completely safe for potable water and food processing.

Q5: What end cap types are available?

A: Standard configurations include DOE (Double Open End) and SOE (Single Open End with gasket/O-ring options) to fit various filter housings.


Specifications

Filter Media: Gradient Melt-Blown Polypropylene (PP)

Standard Length: 10", 20", 30", 40"

Outer Diameter: Standard (approx. 2.5” - 2.6”) / Inner Diameter: approx. 1.1”

Micron Ratings: 1 µm, 5 µm, 10 µm, 20 µm, 50 µm

Operating Temperature: 5°C to 60°C (41°F to 140°F)

End Cap Options: Double Open End (DOE), Single Open End (SOE) options available

Replacement: Disposable cartridge (not recommended for cleaning and reuse)


If you are interested in this filter, please contact us to get the price.

Features

Advanced Gradient Depth Structure: Features coarser pores on the outer layer to trap large particles and finer pores on the inner layer to capture micro-impurities, significantly increasing dirt-holding capacity and extending service life.

100% Food-Grade PP Material: Crafted from pure polypropylene resin without adhesives or surfactants, ensuring safe contact for drinking water and food applications.

Zero Secondary Pollution: Thermal-bonded fiber technology prevents media migration and chemical leaching.

Universal Standard Fit: Compatible with standard 20-inch filter housings on the market, offering easy installation and low maintenance costs.



Model Number

10inch cartridge — Ideal for compact residential water purifiers and under-counter RO systems.

20inch cartridge — Perfect for mainstream small-to-medium industrial pre-filtration and whole-house systems.

30inch cartridge — Designed for medium-flow skid-mounted water treatment equipment.

40-inch cartridge — High-capacity pre-filtration system for heavy-duty commercial and industrial demands.
